NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant

NFC Apple Juice Production Line Pure Squeeze Processing Plant

Lugar de origen Shanghái, China
Nombre de la marca Gofun
Certificación CE, ISO
Número de modelo GFM-APL, GFM-PPL
Detalles del producto
Garantía:
1 año
Servicio postventa proporcionado:
Ingenieros disponibles para dar servicio a maquinaria en el extranjero
Voltaje:
220/380/440V, según clientes
Certificación:
CE/ISO9001
tipo:
Línea de procesamiento llave en mano
Material:
Food Standard SUS 304, 316, According al cliente
Capacidad:
20t/día ~ 1500t/día, según los clientes
Solicitud:
Manzana, pera
Nombre del producto:
Línea de procesamiento de jugo de manzana/pera
Productos finales:
Jugo de NFC, jugo nublado, jugo transparente, jugo concentrado, bebida
Proceso especial:
HPP (procesamiento de alta presión), UHP (procesamiento de presión ultra alta)
Condiciones de pago y envío
Cantidad de orden mínima
1 juego
Precio
negotiable
Detalles de empaquetado
Paquete estándar internacional para envío
Tiempo de entrega
45~90 días
Condiciones de pago
T/T, Unión Occidental, L/C
Capacidad de la fuente
20 conjuntos por año
Descripción del producto

High-Capacity Apple Juice and Puree Processing Plant – 24/7 Automated Operation

Designed for industrial-scale production, our complete apple juice making machinery handles capacities from 24 tons up to an impressive 480 tons of fresh fruit per day . The fully automated PLC control system governs the entire processing workflow—from the initial bubble washing and sorting to crushing, pressing, and enzymatic treatment. This high degree of automation dramatically reduces labor intensity and ensures consistent product quality across every batch .

Whether you are producing clear concentrated apple juice for export, NFC (Not From Concentrate) juice for premium retail, or apple paste for the baking industry, this versatile line delivers. The line incorporates a self-cleaning CIP (Clean-in-Place) system to maintain the highest sanitation standards with minimal downtime. Additionally, our efficient belt press extractor delivers an impressive juice yield of approximately 75% . We also provide customized voltage and power configurations to suit various global factory standards, ensuring seamless integration into your existing facility for immediate productivity gains.


Technical Specifications
Product NameOne-stop solution for apple processing line
Fresh Fruit Inlet Capacity500kg per hour ~ 25 tons per hour, customized
Raw MaterialFresh apple
End ProductsApple pulp, apple puree, apple juice, apple jam, dry apple and more
Final Product Brix10%~12%
Final PackagingAseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
Machine MaterialFood grade SUS304 or SUS316
Warranty12 months after commissioning
Operators RequiredAbout 10~12 persons
Voltage380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Key AdvantagesEnergy-saving, High efficiency, Water-saving, Stable performance
Production Process Overview
1Discharge Platform
Fresh apples are unloaded from trucks using a dedicated platform with water guns and transported to the production line via water flow. This area also serves as a pre-washing station before processing begins.
2Elevator
Transports fresh apples from external receiving areas into the processing facility.
3Washing
Fresh apples undergo thorough cleaning before skin and seed removal. Additional cleaning stages, including ultrasonic and ozone cleaning, can be integrated for enhanced sanitation.
Industrial apple washing machine with multiple cleaning stages
4Sorting
After washing, apples are visually inspected by operators to identify and remove any defective fruit, ensuring only quality produce proceeds to processing.
Quality control sorting station for apple inspection Close-up view of apple sorting conveyor system
5Crushing
GFM-FC series crushers utilize advanced technology for high-precision crushing of apples and other fruits. This fine grinding process enhances the efficiency of subsequent processing stages.
Industrial fruit crusher machine for apple processing
6Preheating
Crushed material is heated to temperatures between 45°C and 85°C. This step improves juice yield in subsequent extraction while preserving color and flavor characteristics.
Temperature-controlled preheating system for apple mash
7Belt Type Juice Extractor
Advanced belt press technology delivers high-efficiency juice extraction with over 70% yield. Features energy-saving design and automated control for optimal performance.
High-capacity belt press juice extractor for apples
8Sterilizing
Tube sterilizers process apple puree and applesauce at ultra-high temperatures (approximately 115°C for 30 seconds) followed by immediate cooling. This preserves taste and nutritional content while ensuring product safety.
Industrial tube sterilization system for apple products Control panel and monitoring system for sterilization process
9Aseptic Filling
Closed-loop aseptic filling systems work in conjunction with sterilizers. The filling chamber maintains vapor protection and sterile conditions, with mirror welding technology ensuring clean, smooth surfaces. Includes CIP and Auto SIP capabilities for various packaging formats.
Aseptic filling machine for sterile packaging of apple products Automated aseptic filling line operation
10Storage or Blending
Finished products can be stored directly or used as raw materials for further processing into apple sauce, ketchup, or other value-added products.
Storage tanks and blending systems for processed apple products
